A.3 Driver Set Operations

The following figure illustrates Modeler operations that are available when you right-click a driver set.

Figure A-3 Driver Set Operations

Table A-3 Driver Set Operations



New > Driver

Launches the Driver Configuration Wizard to add a driver to the driver set.

New > Job

Launches the Job Scheduler Wizard to create a job.

New > Library

Launches the New Library Wizard.

Copy > Driver Set Settings

Enables you to browse to a driver set and copy its settings. A pasted copy overwrites data in the target driver set.

Copy > Global Configuration Values

Enables you to copy Global Configuration Values (GCVs) from one driver set to one or more other driver sets. This option enables you to configure GCVs in one place and then apply GCV settings to selected targets.

Straighten Connections

Straightens all lines in the driver set. If a line is not within a few degrees of being horizontal or vertical, this option is dimmed.

Select Connected Applications

Selects all applications that are connected to the driver set. You can quickly move or delete the applications without browsing to and selecting each one.

Arrange Applications

Arranges application icons around their associated driver set icon. A check mark indicates the current layout for the driver set. After the layout is set, any applications that you connect are automatically snapped into that layout. For more information, see Table A-7.


Evenly distributes applications vertically or horizontally. Press Ctrl, select the items that you want to distribute, then select a pattern.


Aligns applications according to a pattern that you select. Press Ctrl, select the items, then select a pattern (for example, Align Bottom). See Table A-6.

Document Selection

Launches the Document Generation Wizard, which documents the selected driver set.

Import from Configuration File

Reads in exports made from iManager or Designer. For more information, see Section 10.3, Importing a Driver Configuration File.

Export to Configuration File

Exports the driver set to a .xml file. iManager can consume this format, and Designer can re-import it. For more information, see Section 14.10, Exporting To a File.

Live > Import

Enables you to connect to a server, browse to and select objects, and import the objects into the driver set.

Live > Deploy

Prepares a deployment summary and then deploys selected objects and attributes.

Live > Compare

Compares selected driver sets. Enables you to reconcile or update driver sets. See Section 14.7, Using the Compare Feature When Deploying.

Live > Driver Set Configuration > Import Attributes

Imports attributes from an existing driver set.

Live > Driver Set Configuration > Deploy Attributes

Deploys the modified or imported attributes.

Live > Driver Set Configuration > Compare Attributes

Compares attributes in Designer to the connected Metadirectory server.

Live > Status > for All Drivers

Lists drivers that are stopped or running.

Live > Start All Drivers

Starts all drivers associated with the selected object.

Live > Stop All Drivers

Stops all drivers associated with the selected object.

Live > Restart All Drivers

Restarts all drivers associated with the selected object.


Deletes the driver set.


Enables you to configure Identity Vaults, driver sets, drivers, and applications.
