A.6 Internet Agent Port Numbers
|
Protocol |
Default Port Number |
TCP/UDP |
SSL Available? |
Description |
|---|---|---|---|---|
|
MTP |
0 or 7102 |
TCP |
Yes |
Message Transfer Protocol Communication between the GWIA and the MTA The default port number of 0 (zero) configures a direct connection between the GWIA and the MTA, rather than using TCP/IP. Port number 7102 is an example of an administrator-defined MTP port number for a TCP/IP connection. Section 55.1, Changing the Link Protocol between the GWIA and the MTA |
|
HTTP |
9850 |
TCP |
Yes |
Hypertext Transfer Protocol GWIA Web console |
|
SMTP |
25 |
TCP/UDP |
Yes |
Simple Mail Transfer Protocol Communication between the GWIA and email systems across the Internet |
|
POP POP SSL |
110 995 |
TCP/UDP |
Yes |
Post Office Protocol Communication between the GWIA POP email clients |
|
IMAP IMAP SSL |
143 993 |
TCP/UDP |
No Yes |
Internet Message Access Protocol Communication between the GWIA and IMAP clients such as such as Netscape Mail, Eudora Pro, Microsoft Outlook, and Entourage |
|
LDAP LDAP SSL |
389 636 |
TCP |
Yes |
Lightweight Directory Access Protocol LDAP server supporting LDAP queries for GroupWise user information contained in the GroupWise Address Book |
|
SNMP |
161 |
TCP/UDP |
No |
Simple Network Management Protocol Communication between the GWIA and an SNMP management console |
